Coach washing with the SUNRISE W4700
The SUNRISE W4700 is the taller of Europe Makine's two bus gantries, built for double-deck coaches and high-cube trailers. It washes up to 470 cm high and 285 cm wide.
- Sheet
- 02 / 04
- Subject
- Coach wash
- Supplier
- europemakine.com
Height decides the model
The two SUNRISE models share a 285 cm washing width and a 400 cm rail gauge. They differ in height. The W4000 washes to 420 cm and stands 510 cm tall. The W4700 washes to 470 cm and stands 560 cm tall.
For a coach operator, the tallest vehicle in the fleet settles the choice. A double-deck coach calls for the W4700, and the wash hall must give the machine its 560 cm of height.
Both machines measure 465 cm wide without their water shields. The shields add 14 cm on each side.
SUNRISE W4700 dimensions
| Max washing height | 470 cm |
|---|---|
| Max washing width | 285 cm |
| Machine height | 560 cm |
| Machine width, excluding water shields | 465 cm |
| Water shields | 14 cm each side |
| Rail gauge | 400 cm |
| Voltage / frequency | 380 V / 50 Hz |
Brushes or Hydrowash for liveried coaches
The standard SUNRISE washes with brushes in PE plastic or soft brush material. Brushes ride on upright trolleys, with pressure control.
Hydrowash is the brushless option for liveried vehicles. High-pressure water robots work at 20 and 30 bar. The system senses the size of the vehicle, softens dirt with chemicals first, and reaches indented and protruding surfaces.
Wash pressures and chemistry
| Chassis wash | 7.5-10 bar |
|---|---|
| Robotic side wash | 70-100 bar |
| Hydrowash option | 20 and 30 bar |
| Shampoo | 10-20 gr/vehicle |
| Brush material | PE plastic or soft brush |
Programs and controls
SUNRISE carries automatic programs for each vehicle type, so a coach, a single-deck bus and a van each get their own cycle. A manual control option sits alongside them, and the menus are in Turkish and English.
Energy reaches the moving parts through a chain drive, which reduces the load on the gearbox and the motor. Optional accessories install inside the machine's own footprint, so a coach depot can add equipment without giving up space in the hall.
Questions and answers
- Will a double-deck coach fit the SUNRISE?
- The W4700 is the model for double-deck coaches. It washes up to 470 cm high and 285 cm wide.
- Can a coach be washed without brushes?
- Yes, with the Hydrowash option, which uses high-pressure water robots at 20 and 30 bar.
- Does each vehicle type get its own program?
- Yes. SUNRISE has automatic programs for each vehicle type and a manual control option.
- What is the gantry built from?
- A1 grade DKP steel with electrostatic powder coating. Hot-dip galvanization is optional.
- How much shampoo does a coach wash use?
- SUNRISE uses 10-20 gr of shampoo per vehicle.
- Can the W4700 wash trucks and trailers too?
- Yes. Both SUNRISE models wash buses and coaches, rigid trucks, vans and trailers, and the W4700 is the model for high-cube trailers.
Size a coach wash
Give Europe Makine the height and width of your tallest coach and the space in your wash hall. The W4700 proforma costs nothing.
